Description
Isolation Power Systems With Transfer Unit And Isolation Error Detection System
Isolation power panels with transfer units are designed with double source inputs. The transfer unit continuously monitors the selected priority source and transfers the output to the second source in cases such as power outages or voltage levels exceeding the set values. When the priority source returns to nominal values, the output is automatically supplied from the first source again.
In addition to isolation power panels with transfer units, a line monitoring system is included. All output lines are monitored separately via toroidal current transformers. Isolation leakage is detected on a line-by-line basis. Due to the 6 toroidal current transformers, the panels are available with 12, 18 and 24 lines.
• Patient and doctor life safety
• Automatic transfer changeover system
• Transfer time under 100 ms
• 10 kVA isolation power transformer
• Isolation monitoring device
• Fault detection system
• Line-based isolation leakage monitoring
• LCD screen
• 12 / 18 / 24 pcs. 2×16A Type B line outputs
• 0–43A load current
• Transformer temperature monitoring
• Load current monitoring
• Remote monitoring with local and central alarm panels
• Multi-device communication capability
• RS485 Modbus / TCP-IP Modbus communication
Isolation power panels with transfer units are designed with double source inputs. The transfer unit continuously monitors the selected priority source and transfers the output to the second source in cases such as power outages or voltage levels exceeding the set values. When the priority source returns to nominal values, the output is automatically supplied from the first source again.
In addition to isolation power panels with transfer units, a line monitoring system is included. All output lines are monitored separately via toroidal current transformers. Isolation leakage is detected on a line-by-line basis. Due to the 6 toroidal current transformers, the panels are available with 12, 18 and 24 lines.
• Patient and doctor life safety
• Automatic transfer changeover system
• Transfer time under 100 ms
• 10 kVA isolation power transformer
• Isolation monitoring device
• Fault detection system
• Line-based isolation leakage monitoring
• LCD screen
• 12 / 18 / 24 pcs. 2×16A Type B line outputs
• 0–43A load current
• Transformer temperature monitoring
• Load current monitoring
• Remote monitoring with local and central alarm panels
• Multi-device communication capability
• RS485 Modbus / TCP-IP Modbus communication
